Solar Charging Kit | 440W | Victron Smart Solar 100-30 MPPT | Cabling

Complete wiring kit for Solar Panels up to 440W Victron Smart Solar 100/30 MPPT Controller & Cables

With this out of the box Solar Wiring kit you can get your system up and running in no time.

With the reliable and efficient Victron Smart Solar 100/30 MPPT Controller with Bluetooth you can gain maximum efficiency from your system with full productivity visibility.

Included is a 6mm² Charging Cable which is pre-wired and crimped for ease of installation, the cable comes complete with a Midi Fuseholder and 40A fuse. You have a choice of 8mm or 10mm and lengths of 1m to 5m.

Also included is a 5 meter 6mm² pre-crimped Solar PV cable with MC4 connectors for a simple click connection to your Solar Panels.

Save time on your installs with this pre-made wiring kit. All complete with a 5 year warranty.

Victron Smart Solar 100/30 MPPT Charge Controller

A quality MMPT Controller from market leader Victron with Max PV input of 440W (12V) 880W (24V).

This SmartSolar MPPT Controller maximises the output from your Solar Array into usable charging energy.

The MPPT (Maximum Power Point Tracking) is fast in response to shading and works better in low light in the mornings and evenings, this maximises the useful light into power for your system.

Complete with built in Bluetooth for easy monitoring and configuration using the Victron Connect App.

Features & Specifications

Voltage Range: 12V or 24V Automitic Detection

Current Rating: 30A

Max PV Open Circuit Voltage: 100V

Charging: Three stage battery charging (bulk, absorption, float), fully programable

Display: LED Power & Charge Status

Bluetooth Connectivity: Built in, Connect Using the Victron Connect App on iOS or Android

Load Output: Lighting control function, with low voltage and manual disconnect (programable)

Protection: Load output protected against over load and short circuit also protected against reverse polarity connection of the solar panels and/or battery

Dimensions: H130 x W186 x D70mm Weight 1.30Kg

Warranty: 5 Years

Charge Cable Features & Specifications

Fuse Ratings: 40A Fuse

Cable: 6mm² 50A Multistrand DC Cable - 8mm or 10mm Copper Terminal as per selection.

Connectors: 8mm or 10mm Tin Plated Copper Terminals, German T Range Cord Ends.

Fuseholder: Midi

Solar PV Cable Features & Specifications

Cable that is specially designed to be used in photovoltaic systems. These cables are highly UV radiation resistant and operate in a wide range of ambient temperatures (usually from -40°C up to +90°C).

They are weather resistant and guarantee long-life operation.

Cable Certifications: ISO 9001, UKCA & CE

Cable Standard: EN 50618

Cable Lenght: 5 Meters

Core Size: 6mm

Conductor: Tinned Copper Fine Stranded

Diameter: 6.1mm

Min Bending Radius: 5xD

Current Capacity: 30A Inluding MC4 - 70A Cable Only

Max Voltage: AC 1000/1000, DC 1500/1500

Min/Max Operating Tempertature: -40°C/90°C
