Victron SmartSolar 100/20 MPPT 12/24/48V

Victron BlueSolar 100/20 MPPT Solar Charge Controller 100V 20A.

A quality MMPT Controller from market leader Victron with Max PV input of 220W (12V) 440W (24V) 1160W (48V).

This SmartSolar MPPT Controller maximises the output from your Solar Array into usable charging energy.

The MPPT (Maximum Power Point Tracking) is fast in response to shading and works better in low light in the mornings and evenings, this maximises the useful light into power for your system.

Complete with built in Bluetooth for easy monitoring and configuration using the Victron Connect App.

Features & Specifications

Voltage Range: 12V, 24V or 48V Automitic Detection

Current Rating: 20A

Max PV Open Circuit Voltage: 100V

Charging: Three stage battery charging (bulk, absorption, float), fully programable

Display: LED Power & Charge Status

Bluetooth Connectivity: Built in, Connect Using the Victron Connect App on iOS or Android

Load Output: Lighting control function, with low voltage and manual disconnect (programable)

Protection: Load output protected against over load and short circuit also protected against reverse polarity connection of the solar panels and/or battery

Dimensions: H100 x W131 x D60mm Weight 0.65Kg

Warranty: 5 Years
